5.5 Fitting the operating panel
The machine arm has 2 threaded holes to fit the operating panel to.
–
Unscrew the arm cover 1.
–
Attach the external operating panel to the arm with the attachment
bracket 3 and 2 screws.
–
Remove the valve ca p 7.
–
Lay the connection lead 4 of the operating panel -
along the arm and down through the opening in the table plate
or
down through the arm and the base plate - and secure it.
–
Insert the connection plug into the B776 socket of the drive control.
–
Replace the arm cover 1.
–
Replace the valve cap 7.
5.6 Fitting the sewing lamp (optional equipment)
Caution !
Turning off the main switch does not turn off the current to the sewing
lamp.
Remove the mains plug before connecting.
The sewing lamp can be mounted on the arm cover, or on the
operating-panel bracket if present.
If the holder 2 is attached to the arm cover, an M8 thread must be cut
in the relevant hole.
Caution !
The arm cover must be removed for this thread to be cut in the hole.
–
Stick the safety warning label on the front of the main switch 5.
–
Remove arm cover 1.
–
Attach holder 2 to the arm cover 1 or operating-panel bracket 3
with screw and retaining washer.
–
Fit the sewing lamp.
–
Lay the lead in the opening in the machine arm 8.
–
Pass the connection lead down through the hole in the table plate
or the arm and the base plate.
–
Attach the transformer 6 under the table plate with chipboard
screws.
–
Attach the c onnection lead under the table plate with cable ties.
–
Plug in the sewing-light transformer lead.
–
Fit the arm cover 1.
