DURKOPP ADLER 512 - Assembly; Checking the Table Plate; Assembling the Frame

Setup
Operating Manual 512/532 Version 00.0 - 12/201372
8.3 Assembly
8.3.1 Checking the table plate
8.3.2 Assembling the frame
Figure 19: Assembling the frame
CAUTION
Danger of injury from a self-manufactured table
plate of insufficient load-bearing capacity
Ensure that the table plate has sufficient load-
bearing capacity and strength.
The cutouts in self-manufactured table plates must
conform to the dimensions specified in the drawing
(see Appendix).
①
②
(1) – Adjusting screw
(2) – Pedal
(3) – Frame brace
③
