Setup
Operating Manual 512/532 Version 00.0 - 12/2013 75
8.3.5 Setting the working height
Figure 23: Setting the working height
The working height can be adjusted between 750 mm and 950 mm
(measured to the upper edge of the table plate). The frame height
should correspond to the physical characteristics of the operating
personnel.
1. Loosen the screws (2) on both of the frame bars.
2. To avoid jamming, slide the table plate in or out evenly at both
sides.
The scales (1) on the outer sides of the bars serve as an
adjustment aid.
3. Tighten both screws (2).
①
②
(1) – Scale (2) – Screws
