DURKOPP ADLER 745-34-2 - Page 15

For changing the hook thread bobbins:
–
Lift the fabric sliding s heet 2 in the area of pin 1 and swing it to the
left.
For a complete removal (for maintenance and adjusting operations):
–
Lift off the fabric sliding s heets at the pin 3.
1
13
21
3
