2.15.2 Sewing with flap
For the simultaneous sewing-in of flaps or other additional parts the
following optional equipment is required according to the field of
application:
Production of trousers: Flap clamp, right (Order No. 0792 011162)
Production of jackets: Flap clamp, left (Order No. 0792 011161)
Selecting the closing order of the flap clamps
Field of application Position Closing order of the flap clamps
Production of trousers right Right flap clamp closes first
Production of jackets left Left flap clamp closes first
–
Set the closing order of the flap clamps 4 at the control panel
under the
menu item “Program Parameters” (Symbol ).
2.15.2.1 Sewing without light barrier
Shaped guide for flap
The unmachined part 2 is delivered with the flap clamp 1.
It has to be machined as a s haped guide corresponding to the flap
used.
ATTENTION!
The flap length must correspond to the desired length of the pocket
opening.
1
37
12
