2.15.4 Working method B
Piped pockets, automatic feed of the piping strip, without/with incision of the piping ends
Example:
Sew ing pocket openings w ith or w ithout flap in jacket front parts
Loading positions for left and right jacket front parts
–
Position the left jacket front parts 7 at the rear light spot 6.
Position the right jacket front parts 1 at the front light spot 3.
It is useful to generate a pocket program for left front parts (rear
light spot selected) and a pocket program for right front parts (front
light spot selected).
Thus, you only have to alter the pocket program in the main screen
when changing between left and right jacket front parts.
Caution: Danger of injury !
Do not reach into the working area of the positioning device when
triggering the individual steps of the positioning process.
Positioning and starting the sew ing cycle
Example: Right jacket front part
With piping incision
1. Position the piping strip 8 at the front stop 18.
(For the left jacket front part position the piping strip at the rear
stop 9). Position the piping strip also at the lateral stop 19.
2. Step forward on the right pedal and hold it stepped down.
The left flap clamp 14 opens.
3. Position flap 16 at stop 15.
4. Release the right pedal.
The flap clamp 14 closes.
5. Step the right pedal to the back and hold it stepped down.
The right flap clamp 12 opens.
6. Align pocket bag 11 on the rest table 13 at the positioning mark
(e.g. thin adhesive tape).
7. Release the right pedal.
The flap clamp 12 closes.
8. Position the right jacket front part 1 with dart 2 at light spot 4.
9. Align the pocket opening at the lengthwise line of light spot 5
(center knife incision).
46
