DURKOPP ADLER 745-34-2 User Manual

2.11.1 Swinging the corner knife station out / in
The corner knife station 1 can be swung out completely.
Caution: Danger of injury!
Switchthemainswitchoff.
Swing the corner knife station out only with the sewing unit switched
off.
Sw inging the corner knife station out
–
Swing the corner knife station to the left.
The knives are accessible for setting and service work.
Sw inging the corner knife station in
–
Swing the corner knife station back under the sewing unit and let it
catch.
ATTENTION!
The corner knife station must audibly lock when being pushed in.
Note:
If the corner knife station is swung out with the sewing unit switched
on, the following message appears:
1
27
1
1
