Positioning the piping strip
Double piping:
–
Position the piping strip centered on the feeding clamps and flush
with the front edges.
Single piping (left) w ith separately positioned facing (right):
–
Position the piping strip on the left feeding clamp flush with the
cutting line.
–
Position the facing on the right feeding clamp.
This positioning method requires the flap clamp “right” (Order
No.0792 011162) available a s optional equipment.
–
The edges 1 and 2 must be sufficiently seized by the needle, but
must not be cut by the center knife.
Single piping left w ith grow n-on facing
–
Position the piping strip at stop 3 on the left folding plate.
ATTENTION!
With grown-on facing the right folding plate must not close.
Pull off the hose coupling at the right feeding clamp.
36
3
12
