Caution: Danger of injury!
Do not reach into the working area of the positioning device when
triggering the individual steps of the positioning process.
Positioning and starting the sew ing cycle
1. Position the jacket front part on the fabric sliding sheet.
a) Plain goods:
Left jacket front parts:
Position the jacket front part with breast dart 10 at the light spot 9.
Right jacket front parts:
Position the jacket front part with breast dart 10 at the light spot 6.
b) Patterned goods:
Mark the flap edge 11 on the jacket according to the pattern.
Left jacket front parts:
Position the jacket front part with the marking on light spot 12.
Right jacket front parts:
Position the jacket front part with the marking on light spot 7.
2. Align the pocket incision 15 at the lengthwise lines of the
light spots (center knife incision).
The pocket incision 15 is between breast dart 10 and
side seam 4.
3. If additionally equipped with vacuum:
Step forward on the pedal and release.
The vacuum is switched on.
4. Step forward on the pedal.
The transport carriage moves to the loading position.
The feeding clamps lower onto the jacket front part.
For positioning corrections:
Step back on the pedal.
The feeding clamps lift.
Step back on the pedal again.
The transport carriage runs back to the waiting position.
5. Position the piping s trip 16 on the feeding clamps.
Left jacket front parts:
Position the piping strip 16 flush a t the front edges 17.
Right jacket front parts:
Position the piping strip approx. 20 mm behind the light spot 7.
42
