9. Step forward on the left pedal.
The pick-up folder 23 lowers with the piping strip onto the hind
trousers.
The folding sheets c lose.
The piping strip is blown against the folder by air nozzles fitted in
the feeding clamps.
For adjustment see Programming Instructions, chapter 6.4 Modes
“Blow ing of pocket bag/flap”.
For positioning corrections step the left pedal back:
1
st
touch of pedal: The folding sheets open.
The pick-up folder 23 swivels back to
the initial position.
2
nd
touch of pedal: The feeding clamps lift.
3
rd
touch of pedal: The transport carriage moves back to the
waiting position.
10. Step forward on the left pedal.
The feeding device 13 swivels in with flap 14.
11. Step forward on the left pedal.
The flap clamp 24 closes.
Thesewingcyclestarts.
Note
According to the selected pedal mode the sequence of the positions 8
to 11 occurs in inching operation or automatically.
See Programming Instructions, chapter 6.4, for pedal mode selection.
By actuating the key “F3” the piping strip already picked up c an be
released again.
54
