For positioning corrections:
Step back on the left pedal.
The flap clamp 17 opens.
Step back on the left pedal once again.
The feeding clamps lift.
The transport carriage runs back to the waiting position.
12. Step forward on the left pedal.
The positioning process starts anew.
More rapid w orking method for plain goods
For plain goods (no alignment as per pattern) a more rapid working
method can be selected at the control panel (see Programming
Instructions, chapter 6.4).
The steps 1 to 6 of the positioning process remain unchanged.
The steps 7 and 8 are effected as described hereafter:
7. If additionally equipped with vacuum:
Step forward on the left pedal.
The vacuum is switched on.
8. Step forward on the left pedal.
The positioning device 10 turns the breast welt 2.
The gripper 11 moves to the loading area and places
the pocket bag 9 on the jacket front part.
The transport carriage moves to the loading area.
The feeding clamps lower.
The flap clamp 17 opens.
The positioning device 10 places the turned breast w elt 2
on the left feeding clamp.
The flap clamp 17 closes and clamps the breast welt 2.
The positioning device 10 swivels back to the basic position.
The vacuum is switched off automatically.
9. Step forward on the left pedal.
Thesewingcyclestarts.
60
