DURKOPP ADLER 745-35-10 A Service Instructions

Corner knives
Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017 101
To check the corner knife station:
1. Open the menu Service > Machine test menu and press the
button Adjust corner knife ( p. 256).
2. Press the button.
 Reference run is carried out.
3. Press the button.
4. Enter the desired value and confirm by pressing OK.
5. Check the distance between corner knife support (2) and corner knife
support (1).
6.3.1 Checking the front left corner knife (745-35-10 A only)
Fig. 84: Checking the front left corner knife (745-35-10 A only)
To check the front left corner knife:
1. Press the button.
2. Enter the desired value and confirm by pressing OK.
3. Check the distance between corner knife (1) and corner knife (2).
(1) - Corner knife (2) - Corner knife
①②
