Light barriers

Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017 123

8.2.2 Setting the light barriers for the left and the right flap rest

Fig. 105: Setting the light barriers for automatic slant detection (1)

WARNING

Risk of injury from moving parts!

Crushing possible.

Do not reach into the travel path of the transport

clamps.

The folding station must be swung out.

(1) - Template for straight pockets

①
