Easy xLogic User Manual

192
192
192
192
C
C
C
C hapter
hapter
hapter
hapter 7
7
7
7 xLogic
xLogic
xLogic
xLogic Software
Software
Software
Software
xLogicsoft is available as a programming pack age for the PC. This software provides many
features, for example:

A graphic interface for offline creation of your circuit pro gram by means of Function Block
Diagram (function chart)
 Simulation of your circuit program on the PC
 Generating and printing of an overview chart for the cir cuit program
 Saving a backup of the circuit program on the hard drive or other media
 Easy configuration of blocks

Transferring the circuit program
–
from the xLogic to the PC and
–
from the PC to xLogic

Setting the TOD
 Online test: Display of status changes and process vari ables of xLogic in RUN mode:
– Status of a digital I/O, shift register bits and cursor keys
– The values of all analog I/Os
– The results of all blocks
–
The current values (including the times) of selected blocks
–
Change the output(the input pin of the output cannot be connected) status via xLogicsoft
 Starting and stopping circuit program execution via the PC (RUN, STOP).
The
The
The
The xLogic
xLogic
xLogic
xLogic alternative
alternative
alternative
alternative
As you can see, xLogicSoft represents an alterna tive to conventional engineering methods:
1. You start by developing the circuit program on your desktop.
2. You simulate the circuit program on your computer and verify its functions, before you actually
implement it in your system.
3.
You can add comments to the circuit program and create hardcopies.
4.
You save a copy of your circuit program to the file sys tem on your PC, to make it directly
available for any modifications.
5. It takes only a few key actions to download the circuit program to xLogic.
6. Under Simulat e mode in xLogicsoft ,you can study how to program via the panel key
xLogicSoft
xLogicSoft
xLogicSoft
xLogicSoft
xLogicsoft runs under Windows 95/98,
Windows NT 4.0, Windows Me
®
, Windows 2000
®
, Windows XP
®
,windows Vista
xLogicsoft is capable of client/server operation and offers you a high degree of freedom for
creating your circuit program.
xLogicSoft:
xLogicSoft:
xLogicSoft:
xLogicSoft: xLogicV2.
xLogicV2.
xLogicV2.
xLogicV2. 8.5.7
8.5.7
8.5.7
8.5.7
This is the current version of xLogicsoft. You will find all the functions and the functionality of the
devices described in this manual in the version 2. 8.5.7 and later .
