This SFB provides the action of a mechanical pushbutton or switch.
The status of this switch can be changed momentarily in parameter mode. For information
about how to modify, refer to chapter 5 .2.2 please.
Factory
Factory
Factory
Factory state
state
state
state
Default of 'Type' is 'momentary action switch'.
Timing
Timing
Timing
Timing diagram
diagram
diagram
diagram
Description
Description
Description
Description of
of
of
of the
the
the
the function
function
function
function
The output is set, when input En is set and the 'Status' parameter is set to 'On' and confirmed
with OK. This action is performed irrespective of a configured switch or pushbutton function.
The output is reset to '0' in the following threes cases:
• With a 1 to 0 signal transition at input En.
• When a pushbutton function is configured and one cycle has expired after its actuation.
• When the 'Status' parameter sets the 'Off' status in configuration mode, and this has been
confirmed with OK.
Particular
Particular
Particular
Particular characteristics
characteristics
characteristics
characteristics to
to
to
to be
be
be
be noted
noted
noted
noted when
when
when
when configuring
configuring
configuring
configuring
Connection
Connection
Connection
Connection Description
Description
Description
Description
Input En
En
En
En Output Q is set with a 0 to 1 signal transition at input En
(Enable) and if, in addition, 'Status=On' has been
confirmed in configuration mode.
Parameter Type:
Type:
Type:
Type: Sets either a pushbutton action for one cycle or a
switching action of the function.
Status
Status
Status
Status : On or Off state that is applied in the initial cycle
after program startup, is retentivity is not set.
Retentivity
Retentivity
Retentivity
Retentivity set (on) = the status is retentive in memory.
Output Q
Q
Q
Q Output Q remains set 1, as long as En=1 and the status at
the parameter Type = Switch and Status = On.
Output Q is set for the duration of one cycle if EN=1 and the
status at the parameters Type = momentary (pushbutton)
and Status = On.
