Easy xLogic User Manual

81
81
81
81
Connection
Connection
Connection
Connection Description
Description
Description
Description
Parameter At the No1,
No1,
No1,
No1, No2,
No2,
No2,
No2, No3
No3
No3
No3
(cam) parameters you set
the on and off triggers for
each cam of the weekly
timer. The parameter units
are the days and the
time-of-day.
Output Q Q is set when the
configured cam is actuated.
Parameter
Parameter
Parameter
Parameter
You can configure a time hysteresis for each individual cam in parameter mode. For information
about how to modify, refer to chapter 4.2.2 please.
Timing
Timing
Timing
Timing diagram
diagram
diagram
diagram (three
(three
(three
(three practical
practical
practical
practical examples)
examples)
examples)
examples)
No1: Daily: 06:30 h to 08:00 h
No2: Tuesday: 03:10 h to 04:15 h
No3: Saturday and Sunday: 16:30 h to 23:10 h
Description
Description
Description
Description of
of
of
of the
the
the
the function
function
function
function
Each weekly timer is equipped with three cams. You can configure a time hysteresis for each
individual cam. At the cams you set the on and off hysteresis. The weekly timer sets the output
at a certain time, provided it is not already set.
The output is reset at a certain time, provided it is not already reset. A conflict is generated in
the weekly timer when the set on time and the set off time at another cam are identical. In this
case, cam 3 takes priority over cam 2, while cam 2 takes priority over cam 1.
The switching status of the weekly timer is determined by the status at the No1, No2 and No3
cams.
Parameter
Parameter
Parameter
Parameter assignment
assignment
assignment
assignment screen
screen
screen
screen form
form
form
form
View of the parameter assignment screen form, for example for Cam1 and the Pulse setting:
