Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 59
PW9130G1000R-XL2UEU IEC C14-10A L6-20P to C14 coupler
PW9130G2000R-XL2UEU IEC C14-10A L6-20P to C14 coupler
PW9130G2500R-XL2UEU IEC C20-16A L6-20P to C20 coupler
PW9130G3000R-XL2UEU IEC C20-16A L6-20P to C20 coupler
PW9130G1000R-XL2UAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G1500R-XL2UAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G2000R-XL2UAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G3000R-XL2UAU IEC C20-16A Aust. 15A to IEC 320-16A
Table 21. Electrical Input Connections (Tower Models)
Model Input Connection Input Cable
PW9130L700T-XL 5-15P Attached line cord
PW9130L1000T-XL 5-15P Attached line cord
PW9130L1500T-XL 5-15P Attached line cord
PW9130L2000T-XL 5-20P Attached line cord
PW9130L3000T-XL L5-30P Attached line cord
PW9130G1000T-XL IEC C14-10A L6-20P to C14 coupler
PW9130G2000T-XL IEC C14-10A L6-20P to C14 coupler
PW9130G3000T-XL IEC C20-16A L6-20P to C20 coupler
PW9130i700T IEC C14-10A Schuko 10A to IEC 320-10A
PW9130i1000T-XL IEC C14-10A Schuko 10A to IEC 320-10A
PW9130i1500T-XL IEC C14-10A Schuko 10A to IEC 320-10A
PW9130i2000T-XL IEC C14-10A Schuko 10A to IEC 320-10A
PW9130i3000T-XL IEC C20-16A Schuko 16A to IEC 320-16A
PW9130G1000T-XLEU IEC C14-10A L6-20P to C14 coupler
PW9130G2000T-XLEU IEC C14-10A L6-20P to C14 coupler
PW9130G3000T-XLEU IEC C20-16A L6-20P to C20 coupler
PW9130G700T-XLAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G1000T-XLAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G1500T-XLAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G2000T-XLAU IEC C14-10A Aust. 10A to IEC 320-10A
PW9130G3000T-XLAU IEC C20-16A Aust. 15A to IEC 320-16A
Table 22. Electrical Output (All Models)
All Models Normal Mode Battery Mode
Voltage Regulation 2% Nominal output voltage 3%
Efficiency >94% High Efficiency mode for
High Voltage Models
>93% High Efficiency mode for
Low Voltage
Models
>79.5% (700 VA),
>82% (10001500 VA),
>84
% (20003000
VA)
Frequency Regulation Sync with line 3 Hz of nominal line
frequency (outside this range: 0.1 Hz of
au
to-selected nominal frequency)
0.1 Hz of auto-selected nominal frequency
Table 20. Electrical Input Connections (Rackmount Models) (Continued)
Model Input Connection Input Cable
