Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 60
Nominal Outputs Low Voltage Models:
100/110/120/127V (voltage configurable or
auto-sensing)
1000/1500/2000/3000 VA 0.9/1.35/1.8/
2.7
kW
High Voltage Models:
200/208/220/230/240V
(voltage
configurable or auto-sensing)
1000/1500/2000/3000 VA 0.9/1.35/1.8/
2.7
kW
Frequency 50 or 60 Hz, autosensing or configurable as a frequency converter
Output Overload (Normal Mode) 100–102%: Activates Overload alarm. (Level 1)
102–129%: Load transfers to Bypass mode after 12 seconds. (Level 2)
130–49%: Load transfers to Bypass mode after 2 seconds. (Level 3)
>150%: Load transfers to Bypass mode after 100 ms. (Level 4)
Default configuration transfers immediately to Bypass at >102%.
Output Overload (Bypass Mode) 100–109%: Activates Overload alarm. (Level 1)
110–129%: UPS shuts down after 5 minutes. (Level 2)
130–149%: UPS shuts down after 15 seconds. (Level 3)
>150%: UPS shuts down after 300 ms. (Level 4)
Output Overload (Battery Mode) 100–102%: Activates Overload alarm. (Level 1)
102–129%: UPS shuts down after 12 seconds. (Level 2)
130–149%: UPS shuts down after 2 seconds. (Level 3)
>150%: UPS shuts down after 100 ms. (Level 4)
Voltage Waveform Sine wave
Harmonic Distortion <3% THD on linear load; <5% THD on non-linear load
Transfer Time Online mode: 0 ms (no break)
High Efficiency mode: 5 ms maximum (due to loss of utility)
Power Factor 0.9
Load Crest Factor 3 to 1
Table 23. Electrical Output Connections (Rackmount Models)
Model Output Connections Output Cables
PW9130L700R-XL2U (6) 5-15R None
PW9130L700R-XL2US (6) 5-15R None
PW9130L1000R-XL2U (6) 5-15R None
PW9130L1500R-XL2U (6) 5-15R None
PW9130L1500R-XL2US (6) 5-15R None
PW9130L2000R-XL2U (1) L5-20R, (6) 5-20T None
PW9130L2000R-XL2US (1) L5-20R, (6) 5-20T None
PW9130L2500R-XL2U (1) L5-30R, (6) 5-20T,
(2)
20A AC breakers
None
PW9130L3000R-XL2U (1) L5-30R, (6) 5-20T,
(2)
20A AC breakers
None
PW9130L3000R-XL2US (1) L5-30R, (6) 5-20T,
(2)
20A AC breakers
None
PW9130G1000R-XL2U (1) L6-20, (2) 6-20R None
Table 22. Electrical Output (All Models) (Continued)
All Models Normal Mode Battery Mode
