Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 61
PW9130G2000R-XL2U (1) L6-20, (4) 6-20R None
PW9130G2500R-XL2U (1) L6-30R, (1) L6-20R, (2) 6-20R None
PW9130G3000R-XL2U (1) L6-30R, (1) L6-20R, (2) 6-20R None
PW9130i1000R-XL2U (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i1000R-XL2US (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i1500R-XL2U (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i1500R-XL2US (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i2000R-XL2U (8) IEC 320-10A, (1) IEC 320-16A (2) IEC-IEC 10A, (1) IEC 320-16A to Schuko 3-strip
PW9130i3000R-XL2U (8) IEC 320-10A, (1) IEC 320-16A (2) IEC-IEC 10A, (1) IEC 320-16A to Schuko 3-strip
PW9130i3000R-XL2US (8) IEC 320-10A, (1) IEC 320-16A (2) IEC-IEC 10A, (1) IEC 320-16A to Schuko 3-strip
PW9130G1000R-XL2UEU (6) IEC 320-10A None
PW9130G2000R-XL2UEU (8) IEC 320-10A, (1) IEC 320-16A None
PW9130G2500R-XL2UEU (8) IEC 320-10A, (1) IEC 320-16A None
PW9130G3000R-XL2UEU (8) IEC 320-10A, (1) IEC 320-16A None
PW9130G1000R-XL2UAU (4) C13, (2) Aust 10A (2) IEC-IEC 10A
PW9130G1500R-XL2UAU (4) C13, (2) Aust 10A (2) IEC-IEC 10A
PW9130G2000R-XL2UAU (4) C13, (4) Aust 10A (2) IEC-IEC 10A
PW9130G3000R-XL2UAU (4) C13, (1) C19, (3) Aust 10A (2) IEC-IEC 10A, (1) IEC-IEC 15A
Table 24. Electrical Output Connections (Tower Models)
Model Output Connections Output Cables
PW9130L700T-XL (6) 5-15R None
PW9130L1000T-XL (6) 5-15R None
PW9130L1500T-XL (6) 5-15R None
PW9130L2000T-XL (1) L5-20R, (4) 5-20T None
PW9130L3000T-XL (1) L5-30R, (4) 5-20T,
(2)
20A AC breakers
None
PW9130G1000T-XL (1) L6-20, (2) 6-20R None
PW9130G2000T-XL (1) L6-20, (4) 6-20R None
PW9130G3000T-XL (1) L6-30R, (1) L6-20R, (2) 6-20R None
PW9130i700T (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i1000T-XL (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i1500T-XL (6) IEC 320-10A (2) IEC-IEC 10A, (1) IEC 320-10A to Schuko 3-strip
PW9130i2000T-XL (8) IEC 320-10A, (1) IEC 320-16A (2) IEC-IEC 10A, (1) IEC 320-16A to Schuko 3-strip
PW9130i3000T-XL (8) IEC 320-10A, (1) IEC 320-16A (2) IEC-IEC 10A, (1) IEC 320-16A to Schuko 3-strip
PW9130G1000T-XLEU (6) IEC 320-10A None
PW9130G2000T-XLEU (8) IEC 320-10A, (1) IEC 320-16A None
PW9130G3000T-XLEU (8) IEC 320-10A, (1) IEC 320-16A None
PW9130G700T-XLAU (4) Aust 10A None
PW9130G1000T-XLAU (4) Aust 10A None
Table 23. Electrical Output Connections (Rackmount Models) (Continued)
Model Output Connections Output Cables
