4. Operation
4.6 Transfer program to the easyE4 device
Use this dialog box to enter the name that the program should have on the easyE4
device.
Please make sure that this name does not have more than 14 characters (only letters
and numbers are permitted).
Enter a new entry into the input field.
easySoft 7 Project View\Project\Card...
Figure 66: File selection dialog box
The following safety prompt will appear:
Do you want to enter the program as a start program on the card as well?
This prompt is intended for cases in which the easyE4 device
will start running this program as soon as a supply voltage is
applied. If you select the Yes option, please make sure to take
into account the potential automatic startup and the settings
configured in the program
Click on Yes for the test with a sample program from this manual.
easyE4 11/18 MN050009 EN www.eaton.com
117
