Magnefix MD4
991.184 G01 03
105
Description and article numbers of parts not shown in illustrations
Name
Item No.
Spacer for wall-mounted frame, para. item 3.4.1 pos. j
682.204
Cable core clamp for paper-insulated lead-covered cable and plastic-
insulated cable copper core (3 in number) for 12 mm dia. connecting pin
para. 3.5.3
 Universal clamp for cable up to 70 mm
2
682.251
 Concentric clamp for the following cables:
95 - 120 mm
2
682.252
150 mm
2
682.253
185 mm
2
683.257
240 mm
2
683.254
Fasteners for:
 wall-mounted frame, para. 3.4.1 (h)
682.961
 upright frame, para. 3.3.1 (m)
684.541
Long protection cover (L=500 mm) para. (2 required for cable box) 3.8.4
(2 required for cable box)
683.721
7.2 Accessories
Description and article numbers of accessories not shown in illustrations
Name
Item No.
Item No.
High-speed earthing equipment (complete) in bag
685.102
Appropriate switch-on equipment
685.312
Slow earthing equipment for cable panel
complete in
bag
separate
cap
 earthing cap (M10)
683.091
684.568
 earthing cap (M10) with column
685.005
683.766
 earthing cap (ball-head bolt terminal)
685.006
684.412
 earthing cap (ball-head bolt terminal) with column
685.008
685.003
 Earthing equipment for fuse panel
685.102
N.A.
Earthing equipment for fuse panel
complete in
bag
separate
pin
 earthing pin (M10)
684.225
685.768
 earthing pin (ball-head bolt terminal) (without short-circuit conduit)
683.575
685.769
 earthing pin (ball-head bolt terminal)
685.401
685.314
Earthing cable
681.071
Earthing strip for wall-mounted frame
681.826
Earthing strip for upright frame
681.827
Operating rod for earthing cap
684.254
Container of cable grease for cable box, 4 l, containing 3.5 l
6080933
Cheese-head screw M8 x 16 mm
071.426
Filling device complete with filling hose with shut-off ring and filling cover
681.952
Filling device complete with pump, filling hose with shut-off ring and filling
cover
684.016
Pump
681.934
Seperate filling cover for 4 l can.
6080931
Rubber ring (sealing) for filling device
681.953
Spanner for hexagon socket head screws of cable core clamps
681.963
Flexible earth connection for single-core plastic-insulated cable
683.819
Bag for earthing caps
685.140
Filling hose with shut-off ring
681.926
MAC-05 conditioning fluid 0.5 l
685.133
