RACK−MOUNTING THE EPDU
EATON Managed ePDUt User’s Guide S 164201xxx Rev 1 DRAFT 10−OCT−2008
8
See Figure 5 through Figure 7 for other options.
Figure 5. Side Fixing
Figure 6. End Fixing
Figure 7. Blind Fixing
NOTE For side and blind fixing:
S Do not repeatedly slide the bracket along the extrusion. This may degrade the support capability.
S For larger/heavier power strips more than one pair of clip fixings may be used.
