User manual SEFELEC 5x Series 153 v1.06
CONNECTIONS
The input-output signals are accessible on the rear face of the device on terminals C6, C7 and
C8
Note:
Every terminal has
a mechanical coding
Connector C6
Connector C7
Connector C8
1
IN_OUT_0-10V_0
1
Type:
1
N4
2
IN_OUT_0-10V_1
2
MESDCH
2
N5
3
GND10V
3
IN_0-10V_3
3
N6
4
+24VDC
(1)
4
COMOUT
4
N7
5
COMIN
5
CTRLOUT
5
SR0
6
CTRLIN
6
PLCFAIL
6
SR1
7
N0
7
EOT
7
SR2
8
N1
8
PLCPASS
8
SR3
9
N2
9
ERROR
9
IN_0-10V_2
10
N3
10
GND
10
NC
(2)
(1) Unregulated internal 24VDC power supply protected by a resettable PTC fuse, maximum
current 1 A
(2) NC = Not Connected
