14.1.2. MULTIPOINT GROUND CONTINUITY STEP:

The multipoint ground continuity function allows us to define simply a step in the sequence mode

in which several points need to be tested successively for continuity.

To view the drop-down list of the steps press the icon:

Choose the multipoint continuity function from the list of steps:
