User manual SEFELEC 5x Series 195 v1.06
INSTALLATION OF THE SOCKETS IN THE REAR PANEL
REAR PANEL DESCRIPTION
The rear face carries the following elements:
Z1 Mains supply sockets with fuses incorporated
Z2 Ground connection
Z3 Exit area of the measurement cables in the case of the rear face outlet option.
Z4 24-point ribbon connector for the IEEE-488-2 interface
Z5 10-pole terminal block for the safety loop.
Z6 10-pole terminal block for the PLC command.
Z7 10-pole terminal block for the PLC command.
Z8 SUB-D 9-point connector for the control CAN bus of an external matrix
Z9 RJ45 base for the Ethernet connection.
Z10 Mini USB base for the USB connection.
Z11 Fan
Z1
Z9 Z4
Z10
Z6
Z7 Z5
Z2
Z3
Z8
Z11
