DEFINITION OF INPUT-OUTPUT SIGNALS
COMIN (C6-5)
Electrical common line for the input signals.
COMOUT (C7-4)
Electrical common line for the output signals.
CTRLIN (input C6-6)
Request to take over control of the measuring instrument by the PLC.
MES_DCH (input C7-2)
Switching to measurement or discharge.
In the high logic state: Measurement.
In the low logic state: Discharge.
TYPE (input C7-1)
This input corresponds to the previous choice of the measurement function of the XS
range, with the SEFELEC 5x range:
At the low logic state: offsets the memory numbers of 256 positions (256-512)
At the high logic state: does not offset the memory numbers. (0-256)
N0, N1, N2, N3 (inputs C6: 7,8,9,10)
N4, N5, N6, N7 (inputs C8: 1,2,3,4)
Binary encoding enabling the user to select a memory number (0 to 255) and an associat-
ed settings sequence file. See also TYPE input
N7
N6
N5
N4
N3
N2
N1
N0
Memory
File name
0
0
0
0
0
0
0
0
0
Name1
0
0
0
0
0
0
0
1
1
Name2
0
0
0
0
0
0
1
0
2
Name3
0
0
0
0
0
0
1
1
3
Name4
0
0
0
0
0
1
0
0
4
Name5
0
0
0
0
0
1
0
1
5
…
0
0
0
0
0
1
1
0
6
….
0
0
0
0
0
1
1
1
7
….
0
0
0
0
0
1
0
0
8
….
0
0
0
0
1
0
0
1
9
….
….
….
….
….
….
….
….
….
….
….
1
1
1
1
1
1
1
1
255
Name256
The file names only correspond to Sequence files. To run a measurement function alone, put a
call line only for the desired function in the Sequence.
