Eaton SEFELEC 5 Series - Standardized Queries

User manual SEFELEC 5x Series 179 v1.06
*CLS
Positions all standardized registers in the state in which the user finds them at power
on.
*RST
Performs a reset of the device.
WARNING: The unit returns to Local mode, regain control of the device with the
REM command before any other command.
18.1.3. STANDARDIZED QUERIES
*STB?
Returns to the NR1 format and in the hexadecimal base the value of the "STB" register
(e.g.: "#H80").
b0
0 = safety loop open
1 = safety loop closed
b1
0 = no error 1 = error (incorrect voltage, etc.)
b2
0 = End of test 1 = Test In Progress
b3
0 = Test FAIL 1 = Test PASS
b4
Not used
b5
Or Logic of the bits of the ESR Register
b6
Or Logic of the bits of the STB Register
b7
Not used
*SRE?
Returns to the NR1 format and in the hexadecimal base the value of the "SRE" register
(STB register mask)
*ESR?
Returns to the NR1 format and in the hexadecimal base the value of the register "ESR"
b0 to b3
Not used
b4
1 = type 2 dialogue error (digital value outside limits, command out of context)
b5
1 = type 1 dialogue error (incorrect syntax)
b6
Not used
b7
1 = Switching on the power
Note: The bits are reset after reading by the *ESR? command.
