User manual SEFELEC 5x Series 95 v1.06
NOTE
Press the Start button. For safety reasons, it is necessary to press the button
for > 1 second for the device to switch into measurement mode. If the button is
pressed for too short a time a message will be
displayed momentarily on the
The measurement cycle takes place according to the Rise, Hold and Fall times with the display
of the voltage and current according to the following screen:
At the end of the test the display shows if the measurement is between Rmin and Rmax i.e. con-
sidered PASS.
START
