User Manual
Using the System
24
The cursor is now located in a position not already occupied by a field, so type in the word”BATCH”:
Now use the right arrow key to move the cursor one space to the right, ready to accommodate the
sequential number field. Note that, as mentioned earlier, moving the cursor in this way automatically
defines our “BATCH”text as a text field.
Press [F3] (Field Type) from the EDIT MESSAGE screen and this will display the SELECT FIELD TYPE
menu:
Use the menu cursor to locate the Sequential No. option and press the [enter] key. The SEQUENTIAL
NUMBER menu will be displayed:
Reset Number Used to reset the Current Number to the Start Number and set the Repeat
Count to zero.
Current Number Displays the current number
St
art Number Up to 10 alphanumeric characters
End Number Up to 10 alphanumeric characters
Interval Value by which to increment or decrement. For example if this was set to 5
with a Start Number of 00, the counting sequence would be 0, 5, 10, 15, and
so on. Range 1 through 127
No. of Repea
ts Number of times the sequential number will be printed before it is
incremented by the Interval value set above.
Range 1 through 65535
Repeat Count Number of times the sequential number has been printed for its current
value. Maximum value No. of Repeats minus 1.
Repeated Count 0
Decremental Count
To count down from a number, simply set the End Number to a value less than the Start Number.
EDIT MESSAGE
F1： 2FspaC HGIH 7 ：Bold Off
F3： 4FepyT dleiF ：Key-Name
VOD PRESSURE PHASE
00000
000
Jet Off 2006-03-24 14:01:38
EJ44
TEST
1
Sell by dd mmm yy
EDIT MESSAGE
F1： 2FspaC HGIH 7 ：Bold Off
F3： 4FepyT dleiF ：Key-Name
VOD PRESSURE PHASE
00000
000
Jet Off 2006-03-24 14:01:38
EJ45
TEST
1
Sell by dd mmm yy
BATCH
SELECT FIELD TYPE
VOD PRESSURE PHASE
00000
000
Jet Off 2006-03-24 14:01:38
Time
Timed Message
> Sequential No.
Date
EJ46
SEQUENTIAL NUMBER
VOD PRESSURE PHASE
00000
000
Jet Off 2006-03-24 14:01:38
Reset Number
Hexadecimal
Common Number
> Start Number
EJ47
