Appendix 1:Installations & Setting Up
Appendix 1: Installation & Setting Up
This appendix is to help you install and set up the printer. Normally this procedure will be carried out
by EC-JET Service Engineers when commissioning a new printer.
These notes are provided as a guide to be used if the printer is relocated or changes are made to
ancillary equipment. Guarding and safety interlocks should all be in place and working correctly. EC-
JET can accept no liability for damage to either machine or personnel in the event of the printer being
installed, moved or maintained by unauthorised and/or untrained personnel. If you are unsure of any
procedure it is recommended that you contact your local EC-JET distributor.
Unpacking the System
Carefully remove the cardboard packaging and check for the following contents:
- EC-JET printer
- EC-JET User Manual
- Final test print sample sheet
- Total Quality Plan packing card
- Key for cabinet
- A Guide to Quick Use
Where to put the Printer
The EC-JET printer must be sited on a firm, solid base (preferably a EC-JET cabinet or mounting table)
and with a clean power supply, i.e. free from electrical interference.
The printer physical dimensions, in millimetres, are as follows:
550 (wide) x 230 (high) x 450 (deep).
The printer weighs 23 kg (not including ink or packaging).
Accessories
The following accessories are available for purchase with the EC-JET printer:
- RS232 Communications Cable - allows multiple, remote printer control from Windows based
PC system
- Shaft Encoder - enables even print width at uneven line speeds
- Photocell - detects presence of product
- Printhead Gantry
- Waterproof printer and printhead covers
- Positive Air Kit - to prevent dust interfering with print quality
For a full list of all available accessories, please contact EC-JET or your EC-JET distributor.
Power Connection
The EC-JET range of printers are designed to operate on a single phase, 50/60 Hz AC supply of 90 to
240 V at 50/60 Hz. This means that any AC voltage within this range will power the printer satisfactorily.
Please check that the details shown on the label at the rear of the printer match your power source before
switching on.
Before connecting to the power supply, make sure the power-on switch is in the off position.
The power rating of the printer is 200 VA.
The wires in this electrical supply lead are coloured in accordance with the following code:
To Next Page
