71 User Manual
Technical Specification
Level Control
Ink tank sense low: Warning reported at approximately 750 ml
Solvent tank sense low: Warning reported at approximately 750 ml
Performance
Solvent consumption: <8 ml/h at 20 Celsius ambient using EC1240 MEK black ink
Memory Capacity
Message storage capacity: Up to 46 messages
Logo storage capacity: Up to 120 logos
Chinese Character: 12000 inside
Printhead
Types
Micro: 40 micron
Midi: 60 micron and 70 micron
Macro: 100 micron
Construction
Printhead: Machined Acetal body
Cover tube: Stainless steel grade 304
Conduit adaptor: Stainless steel grade 303
Dimensions
Conduit length: 2 m
Throw Distance (recommended)
Micro: 3.5 mm
Midi: 10 mm
Macro: 20 mm
Printing Performance Data
Raster Information
Lines of print: Maximum two lines of 16 High characters, or up to four lines of 7 High
characters
Rasters available: Paired raster set (printer model dependent ) of 7 STD, 7 Min,
7 HS, 12 STD, 12 HS, 16 STD, 16 HS, 16 SHS, 24 STD, 32 STD,
34 STD
Character Height Range
Minimum character height: 1.2 mm (Micro printhead) using 7 Min raster
Maximum character height: 16.5 mm (Midi printhead) using 34 raster
