70 User Manual
Technical Specification
Technical Specification
Introduction
The EC-JET Continuous Ink Jet Printer is a fast, reliable, non-contact printer capable of applying sell-
by dates, batch codes and other variable information to a wide range of substrates on the production
line.
Technical Data
Cabinet
Construction
Base tray unit: Stainless steel grade 304
Top cover: Stainless steel grade 304
Dimensions
External height: 230 mm
External width: 450 mm
External depth: 550 mm
Weight
Printer weight: 23 kg (excluding ink, solvent and packaging)
Power Requirements
Voltage: 90 V (3 A) to 240 V (1.5 A) a.c., 50/60 Hz
Power rating: 200 VA
This equipment is a Class 1 earthed Electrical connections at the rear of the cabinet comply with the
extra low voltage safety requirements.
WARNING: THIS PRINTER MUST BE EARTHED/GROUNDED.
Environmental
Operating temperature: +5 to +45 Celsius ambient
Humidity range: Up to 90% relative humidity, non-Ccondensing
Acoustic emission: Less than 70 db
Ink System
Construction
System enclosure: Stainless steel grade 304
Ink tank: MDPE natural
Solvent tank: MDPE natural
Capacity
Ink tank: 1800 ml approximately
Solvent tank: 1800 ml approximately
Pressure
Pressure range: Up to 4.48 bar (65 p.s.i.) normal operating pressure
Maximum pressure: 6.2 bar (90 p.s.i.) maximum under fault conditions
