55 User Manual
Troubleshooting
Top (or bottom) of pattern missing
Gutter Clipping………………………………………………………………………………… FC05
Section of the pattern missing or distorted.
Printhead Cover Catch (obstruction in cover slot)…………………………………………FC06
Uneven stretching of the pattern.
Shaft Encoder Faults (shaft encoder slipping)………………………………………………FC09
Squashed print. Pattern not blurred.
Deflector Voltage Faults………………………………………………………………………FC10
Product tilting along the axis of the conveyor travel.
Vibration Problems…………………………………………………………………………… FC36
Product tilting across the axis of the conveyor travel.
Vibration Problems…………………………………………………………………………… FC36
High frequency vibration along the axis of the conveyor travel.
Vibration Problems…………………………………………………………………………… FC36
High frequency vibration across the axis of the conveyor travel.
Vibration Problems…………………………………………………………………………… FC36
