Page #23 background image
AS9216 Installation and
Maintenance Manual
AS9216 Description
492006-2306-013-A00 ECI Telecom Ltd. Proprietary 2-5
The Front Panel LEDs
The below table lists the AS9216 LEDs and their role:
Table 2–1: AS9216 LEDs
Area Label Description Status
System 1 STS
the general
device
software
status
Off: the device is processing the boot
loader
Green (fast blink): the device is
initializing the application
Green: normal operation
2 FLT
the general
device
hardware
fault
Off: device hardware is OK
Red: the CPU cannot boot
Blinking Red: a failure during BIST
3 MNG
software
management
activity
indicator
Off: no management activity
Blinking Green: a current
management activity
4 ETH
link and
activity
indicator
Off: link down
Green: link up
Blinking Green: current link activity
Power
supply
5 PS
9216-ACPS,
9216-DCPS
status
indicator
(1 & 2)
Green: 9216-DCPS or 9216-ACPS
providing power to the main board
Red: 9216-DCPS or 9216-ACPS is
not providing power to the main board
6 PWR
9216-DCPS
power status
Off: power off
Green: power on
7
Invert
CON
9216-DCPS
reverse
polarity status
Off: polarity is OK
Red: polarity is reversed
Fans 8
9216-
FAN
9216-FAN
status
Off: 9216-FAN is removed
Green: 9216-FAN is operating
successfully
Red: one or more 9216-FANs are not
operating
