ECI AS9216 - Specifications; Physical Specifications; Power Source Specifications

492006-2306-013-A00 ECI Telecom Ltd. Proprietary 7-1
The following tables list the AS9216 device specifications.
Table 7–1: Physical Specifications
Width 440 mm (<19”)
Height 89 mm (2RU)
Depth 305 mm (12”)
Weight
Chassis without 1
9216-DCPS or
9216-ACPS
7.7 kg (16.97 lbs)
Single Power Supply 0.6 kg (1.3 lbs)
Table 7–2: Power Source
AC Power Source Voltage: 90-132/180-240 Vac, 4/2A
Frequency: 50/60Hz
Typical Power
consumption
150 W
DC Power Source Voltage 36 to 75 VDC, 6A
Typical Power
consumption
130 W
7
Specifications
