Specifications AS9216 Installation and
Maintenance Manual
7-2 ECI Telecom Ltd. Proprietary 492006-2306-013-A00
Table 7–3: Operating Conditions
Operating temperature: 0° C to 45° C (32 °F to 113 °F)
Short term extended
temperature:
-20° C55° C (-4°F131° F)
Humidity: 0–95% non-condensing
Environment:
The equipment is designed for use in indoor applications
only
Relative Humidity: 5% to 90% non-condensing
Operating Altitude: 6,600 ft (2,012 m)
Storage Temperature: -25º C to 70º C (-13º F to 158° F)
Storage Humidity: 95% maximum relative humidity, non-condensing
Storage Altitude: 15,000 ft (4,500 m) maximum
Table 7–4: Management Features
Inband Integrated SNMP agent
Telnet
SSH
MIBs Supported
MIB II, Bridge MIB, Private MIB ,RMON MIB (Groups
1,2,3,9)
Traps/Alarms SNMP traps to NMS
Console Port For initial configuration via dedicated RJ-45 connector
EIA 232 protocol
VT-100 compatible
Out-of-band Ethernet
Port
For Software Update via dedicated RJ-45 connector
Software Download Via TFTP
