3.5 Product Modes
There are 5 modes in total: Normal mode, Setting mode, Max/Min value
mode, Alarm setting mode, MAC address display.
3.5.1 Normal Mode
1. The product will enter the main page of Normal mode by default when
it is normally powered on. In other modes, no button operation for 30
seconds or press
LIGHT
can also return to the main page of normal mode.
2. In Normal mode, press
SET
to change the mode.
Sequence: Normal mode -> Maximum value -> Minimum value -> Alarm
setting -> MAC address display.
3. Press TEMP in Normal mode to switch the display: OUTDOOR ->
FEELSLIKE -> DEW -> CH1 -> CH2 -> CH3 -> CH4 -> CH5 -> CH6 -
> CH7 -> CH8 -> Auto-Scroll mode.
4. When the OUTDOOR, FEELSLIKE and DEW show the states, hold
the TEMP for 5 seconds to re-register the outdoor temperature and
humidity sensors.
5. If the
TEMP
is held for more than 5s in single CH mode, the
corresponding CH sensor transmitter will be re-registered.
6. If the TEMP is held for more than 5s in Auto-Scroll mode, it will re-
register the Outdoor and CH1~CH8 sensors. Same as 4. above, need to
DISABLE other registered priority transmitters first.
①
Press
RAIN1
to switch RAIN RATE/EVENT. The bar chart on the
right side synchronizes the graphical display of its values.
② Press RAIN2 to switch RAIN DAILY/ WEEKLY/ MONTHLY/
YEARLY/ TOTAL.
7. Press
WIND
can switch WIND/GUST/DIRECTION/10min direction
display. Numbers indicate the angle of the wind direction.
