Specifications
Table 2-5: Type D Thermocouple (°C)
Temperature Range
Error After:
30 Days Six Months One Year
0 <100
±0.16 ±0.23 ±0.27
100 <300
±0.12 ±0.17 ±0.20
300 <1400
±0.10 ±0.13 ±0.15
1400 <1650
±0.10 ±0.15 ±0.17
1650 <1930
±0.12 ±0.16 ±0.20
1930 <2100
±0.14 ±0.19 ±0.23
2100 <2200
±0.15 ±0.21 ±0.25
2200 2320
±0.18 ±0.25 ±0.30
Table 2-6: Type D Thermocouple (°F)
Temperature Range
Error After:
30 Days Six Months One Year
32 <212
±0.29 ±0.41 ±0.49
212 <572
±0.22 ±0.31 ±0.36
572 <2552
±0.18 ±0.23 ±0.27
2552 <3002
±0.18 ±0.27 ±0.31
3002 <3506
±0.22 ±0.29 ±0.36
3506 <3812
±0.25 ±0.34 ±0.41
3812 <3992
±0.27 ±0.38 ±0.45
3992 4208
±0.32 ±0.45 ±0.54
Table 2-7: Type E Thermocouple (°C)
Temperature Range
Error After:
30 Days Six Months One Year
−270 <−245 ±0.95 ±1.10 ±1.20
−245 <−195 ±0.13 ±0.16 ±0.18
−195 <−155 ±0.07 ±0.09 ±0.10
−155 <−90 ±0.06 ±0.07 ±0.08
−90
<15
±0.05 ±0.06 ±0.07
15 <890
±0.05 ±0.06 ±0.06
890 1000
±0.05 ±0.06 ±0.07
Table 2-8: Type E Thermocouple (°F)
Temperature Range
Error After:
30 Days Six Months One Year
−454 <−409 ±1.71 ±1.98 ±2.16
−409 <−319 ±0.23 ±0.29 ±0.32
−319 <−247 ±0.13 ±0.16 ±0.18
−247 <−130 ±0.11 ±0.13 ±0.14
−130
<59
±0.09 ±0.11 ±0.13
59 <1634
±0.09 ±0.11 ±0.11
1634 1832
±0.09 ±0.11 ±0.13
2-5
