Operation
Table 4-2: Default Settings
Parameter Setting
Thermocouple type / Output K-MN175* / 0.00°C
Thermocouple offset units System units
Thermocouple offset 0.00°C
Reference-junction-temperature units System units
Reference-junction temperature 0.00°C
Instrument mode Source
Output mode Temperature
System temperature units Celsius (°C)
System voltage units Volts (V)
Temperature resolution limit 0.01°
Voltage resolution limit 0.1 µV
Temperature scale ITS-90
Material Alloy
Terminals Thermocouple connector
Copper offset units System units
Copper voltage offset 0.000000 V
Autozero enabled No
Autozero temperature offset
+0.00°C
DIAGNOSTICS MENU
KEYPAD TEST
LCD TEST
ABOUT
Figure 4-14: Diagnostics Menu
Diagnostics Menu
The DIAGNOSTICS MENU is provided for the user to verify that the KEYPAD switches and the
LCD display bits are working properly.
Keypad Test
Select KEYPAD TEST to test any front-panel control for proper operation. The screen will indicate
any signal received from the front-panel controls, such as 6 PRESSED, ENTER RELEASED,
DECIMAL POINT HELD, or ENCODER TURNED CLOCKWISE. Press ESC when finished.
LCD Test
Select LCD TEST to test all the bits on the display. Initially, a horizontal bar slowly moves up and
down on the screen. By pressing either the up or down ARROW KEY or turning the ENCODER, the
user can manually control the position of the line to more closely observe the display bits.
4-22
