Patient Monitor User Manual Recording
- 123 -
NOTE:
You can press the
button on the front panel to stop the currently recording process.
22.5 Recorder Operations and Status Messages
22.5.1 Record Paper Requirement
Only standard thermosensitive record paper can be used: otherwise the recorder may not function,
the recording quality may be poor, and the thermosensitive printhead may be damaged.
22.5.2 Proper Operation
■ When the recorder is working, the record paper goes out steadily. Do not pull the paper
outward with force: otherwise the recorder may be damaged.
■ Do not operate the recorder without record paper.
22.5.3 Paper Out
When the Recorder Out OF Paper alarm is displayed, the recorder cannot start. Please insert
record paper properly.
22.5.4 Replacing Paper
1. Pull outwards the upper arc part of the recorder casing to release the casing, shown in the
following figure.
2. Insert a new roll of paper into the paper cassette, printing side facing upwards.
To Next Page
