EDAN iM80 - Technical Alarm Information

Patient Monitor User Manual Alarm Information
- 30 -
FiDES Low FiDES measuring value is below lower alarm limit. User-selectable
AG FiO
2
Low FiO
2
measurement value is too low. High
AG APNEA
In a specific time interval, no RESP can be detected
using AG module.
High
TB High TB measuring value is above upper alarm. User-selectable
TB Low TB measuring value is below lower alarm. User-selectable
5.2 Technical Alarm Information
NOTE:
The ECG alarm information listed in the below table describes the lead names in
America. For the corresponding lead names in Europe, please refer to Section Installing
Electrodes.
Message Cause Alarm Level Action Taken
ECG Lead Off
More than one ECG
electrode falls off the skin or
ECG cables fall off the
monitor.
Low
Make sure that all
electrodes, leads and
patient cables are
properly connected.
ECG V Lead Off
ECG electrode V fal
ls off
the skin or ECG cables fall
off.
Low
ECG LL Lead Off
ECG electrode LL falls off
the skin or ECG cables fall
off the monitor.
Low
ECG LA Lead Off
ECG electrode LA falls off
the skin or ECG cables fall
off the monitor.
Low
ECG RA Lead Off
ECG electrode RA falls off
the skin or ECG cables fall
off the monitor.
Low
ECG Signal Exceed
ECG measuring value is
beyond measuring range.
High
Check lead
connection and
patient condition
