Patient Monitor User Manual Product Specification
- 154 -
A.9 RESP
Method
Trans-thoracic impedance: R-F(RA-LL), R-L (RA-LA)
Respiration excitation
waveform
< 300 μA, sinusoid, 62.8 kHz (± 10%)
Measuring sensitivity
0.3 Ω (base impedance 200 to 4500 Ω)
Base impedance range
200 to 2500 Ω (cable resistance = 0 K)
2200 to 4500 Ω (leads cables 1KΩ resistance)
Differential input impendence
> 2.5MΩ
Waveform bandwidth
0.2 to 2.5 Hz (-3 dB)
RR measuring range:
Adult
0 to 120 rpm
Neo/Ped
0 to 150 rpm
Resolution
1 rpm
Accuracy
±2 rpm
Apnea Alarm Time Setup
10s, 15s, 20s, 25s, 30s, 35s, 40s
A.10 NIBP
A.10.1 NIBP from EDAN Module
Method
Oscillometric
Mode
Manual, Auto, Continuous
Measuring interval in AUTO
Mode
1/2/3/4/5/10/15/30/60/90/120/240/480 min
Continuous
5min, interval is 5s
Measuring type
SYS, DIA, MAP
Measuring Range
Adult mode
SYS: 40 mmHg ~ 270 mmHg
DIA: 10 mmHg ~ 215 mmHg
MAP: 20 mmHg ~ 235 mmHg
Pediatric mode
SYS: 40 mmHg ~ 200 mmHg
DIA: 10 mmHg ~ 150 mmHg
MAP: 20 mmHg ~ 165 mmHg
Neonatal mode
SYS: 40 mmHg ~ 135 mmHg
DIA: 10 mmHg ~ 100 mmHg
