Patient Monitor User Manual Product Specification
- 161 -
For C.O. < 4.0 L/min: 0.2 L/min
TB
±0.1°C
TI
±0.1°C
NOTE：
At least 90% of the C.O. data should reside inside the bounded region, and the lower
95% confidence interval should not exceed 85%.
A.17 AG
A.17.1 Phasein Sidestream
Module Type
ISA AX+ Analyzer
Displaying the concentration of CO
2
, N
2
O,
and two anaesthesia agent and identifying the
anaesthesia agent automatically (portable
module)
ISA OR+ Analyzer
Displaying the concentration of CO
2
, O
2
, N
2
O,
and two anaesthesia agent and identifying the
anaesthesia agent automatically (portable
module)
Measurement
Parameters
CO
2
, N
2
O , O
2
, Halothane (HAL), Isoflurane(ISO), Enflurane(ENF),
Sevoflurane(SEV) , Desflurane(DES), awRR, MAC
Measurement
Principle
CO
2
, N
2
O, Anaesthesia Agent: infra-red absorption characteristic;
O
2
: Paramagnetic method
Sampling Flow
Rate
50 ml/min
Work Mode
Measurement, Standby
Warm-up Time
< 20s
Typical Rise Time
CO
2
≤ 200ms
O
2
≤ 350ms
N
2
O ≤ 350ms
O
2
≤ 450ms
Primary
Anaesthesia Agent
Threshold
≤ 0.15 vol%
Second Anaesthesia
Agent Threshold
0.2 vol% + 10%
Agent
Identificaiton Time
< 20 seconds (typically < 10 seconds)
