EDAN iM80 - 4.3 Controlling Alarm

Patient Monitor User Manual Basic Operation
- 12 -
iM50 Side View
1
Sensor interface
2
Recorder door
3
Battery door
3.1.2 iM80 Major Parts and Keys
The iM80 patient monitor has a 15-inch TFT color flat panel display. Up to 13 waves can be
shown on iM80 screens.
iM80 Front View
1
Alarm indicator — when an alarm occurs, the alarm indicator will light
1
2
3
