The high/medium/low-level alarms are indicated by the system in following different ways:
Alarm
level
Prompt
Physiological alarms
Technical alarms
High
Mode is
“DO-DO-DO------DO-
DO,
DO-DO-DO------DO-D
O”, which is triggered
once every 5 seconds.
The alarm indicator
flashes in red, with a
frequency of 1.4Hz ～
2.8Hz.
The alarm
message flashes with red
background
, and the
symbol *** is displayed at
the alarm area.
The alarm indicator
flashes in red. The alarm
message flashes with red
background
, and the
symbol *** is displayed at
the alarm area.
Medium
Mode is “DO-DO-DO”,
which is triggered once
every 25 seconds.
The alarm indicator
flashes in yellow, with a
frequency of 0.4Hz ～
0.8Hz.
The alarm
message flashes with
yellow background
, and
the symbol ** is
displayed at the alarm
area.
No definition
Low
Mode is “DO-”, which
is triggered once every
30 seconds.
The alarm indicator
flashes in yellow
. The
alarm message flashes
with yellow background,
and the symbol * is
displayed at the alarm
area.
The alarm indicator
flashes in blue. The alarm
message flashes with
yellow background
, and
the symbol * is displayed
at the alarm area.
The sound pressure range for audible alarm signals is from 45 dB to 85 dB.
4.3 Controlling Alarm
4.3.1 Switching the Individual Alarm Off
To switch the alarm off, please select XX Setup > Alarm Setup (XX stands for parameter name)
and set Switch to Off from the popup list. Alarm Off symbol
is displayed on the parameter
area if the parameter alarm is switched to off.
4.3.2 Temporary Alarm Mute
The monitor will give an audible alarm when there is an alarm during the audio alarm pause and
the alarm indicator and screen flash indicating there is an alarm. The top of monitor displays the
following:
1. Alarm pause symbol
.
2. The remaining pause time is displayed in text and the word background is red.
