Patient Monitor User Manual Alarm Information
- 42 -
Excessive Temp, C.O.
Measurement Fail.
C.O. measuring needs parameters.
C.O. measure need param HEMOD calculation needs parameters.
Insufficient factors for Hemod
Dynamics
HEMO Dynamics calculation needs parameters.
No Sensor, C.O. measurement
fail
No Sensor,C.O. measurement fail
Measuring... The C.O. module is performing measuring.
Ready for new measurement C.O. module is ready for new measurement.
Invalid C.O. result C.O. measurement result is invalid.
C.O. Measurement Complete C.O. Measurement is completed.
C.O. Measurement Abort C.O. Measurement is aborted.
Warm-up over The monitor displays this message after taking the sensor
out of the bracket and warm-up is over.
Measure over After the Predict measuring is over, the data and message
display on the interface.
Measure time out No measuring result after the module entering Predict
state for 30s.
AG Standby AG module is operating in the standby status.
5.4 Adjustable Range of Alarm Limits
ECG alarm limits are listed as follows: unit (bpm)
Patient Type
ALM HI
ALM LO
HR
ADU
300
15
PED
350
15
NEO
350
15
ST analysis alarm limits are listed as follows: unit (mV)
ALM HI
ALM LO
ST
2.0
-2.0
PVCs alarm upper limits are listed as follows:
ALM HI
ALM LO
PVCs
10
RESP alarm limits are listed as follows: unit (rpm)
Patient Type
ALM HI
ALM LO
ADU
120
6
