EDAN iM80 - Page 164

Patient Monitor User Manual Product Specification
- 153 -
COUPLET
TACHY
BRADY
VT>2
BRADY
PNC
BIGEMINY
MISSED BEATS
PNP
TRIGEMINY
IRR
VENT
VBRADY
12-lead ECG
Synchronization Analysis
Average parameters of heart beat
Heart rate (bpm)
Time limit of P wave (ms)
PR interval (ms)
QRS interval (ms)
QT/QTC (ms)
P-QRS-T AXIS
ECG Analog Output
Bandwidth (-3dB)
Diagnosis: 0.05Hz ~ 100Hz
Monitor: 0.5Hz ~ 40Hz
Surgery: 1Hz ~ 20Hz
Max transmission delay
500ms (in diagnostic mode, and with notch off)
Sensitivity
1V/mV ±10%
PACE
rejection/enhancement
Without Pace enhancement or pace rejection
Defib Sync Pulse
Output wave
Square pulse
Output impedance
50Ω
Delay from R-wave peak to
start of pulse
35ms
Amplitude
High level: 3.5 to 5 V, providing a maximum of 1 mA output
current;
Low level: < 0.5V, receiving a maximum of 5 mA input current.
Minimum required R wave
amplitude
0.3mV
Pulse width
100ms ± 10%
Limited current
15 mA rating
Rising and falling time
< 1 ms
