Patient Monitor User Manual Alarm Information
- 31 -
ECG Signal Overflow
The amplitude of ECG
signal is too wide.
Low
Plea
se modify the
ECG gain.
ECG Comm Fail
ECG module failure or
communication failure
High
Stop measuring
function of ECG
module, and notify
biomedical engineer
or manufacturer’s
service staff.
ECG Noise
ECG measuring signal is
greatly interrupted.
Low
Check lead
connection and
patient condition
ECG V1 Lead Off
ECG electrode V1 falls off
the skin or ECG cables fall
off.
Low
Make sure that all
electrodes, leads and
patient cables are
properly connected.
ECG V2 Lead Off
ECG electrode V2 falls off
the skin or ECG cables fall
off.
Low
ECG V3 Lead Off
ECG electrode V3 falls off
the skin or ECG cables fall
off.
Low
ECG V4 Lead Off
ECG electrode V4 falls off
the skin or ECG cables fall
off.
Low
ECG V5 Lead Off
ECG electrode V5 falls off
the skin or ECG cables fall
off.
Low
ECG V6 Lead Off
ECG electrode V6 falls off
the skin or ECG cables fall
off.
Low
RESP Comm Fail
RESP module failure or
communication failure
High
Stop measuring
function of RESP
module, and notify
biomedical engineer
or the manufacturer’s
service staff.
