Patient Monitor User Manual Product Specification
- 148 -
Ventricular Rhythm
The interval of 5 consecutive ventricular wave ranges from
600 ms to 1000 ms
Ventricular Bradycardia
The interval of 5 consecutive ventricular wave is more than
1000 ms
Startup time for Tachycardia
Ventricular Tachycardia
1 mV 206bpm
Gain 1.0: 10 s
Gain 0.5: 10 s
Gain 2.0: 10 s
Ventricular Tachycardia
2 mV 195bpm
Gain 1.0: 10 s
Gain 0.5: 10 s
Gain 2.0: 10 s
Response time of Heart Rate
Meter to Change in HR
HR range: 80 bpm ~ 120 bpm
Range : 7s ~ 8s, average is 7.5s
HR range: 80bpm ~ 40bpm
Range : 7s ~ 8s, average is 7.5s
Tall T-wave Rejection
Exceeds ANSI/AAMI EC13-2002 Sect. 4.1.2.1 C)
minimum recommended 1.2mV T-Wave amplitude
Accuracy of Heart Rate Meter
and Response to Irregular
Rhythm
Complies with ANSI/AAMI EC13-2002 Sect.4.1.2.1 e)
The HR value displays after a stable period of 20s:
Ventricular bigeminy: 80bpm±1bpm
Slow alternating ventricular bigeminy: 60bpm±1bpm
Rapid alternating ventricular bigeminy: 120bpm±1bpm
Bidirectional systoles: 91bpm±1bpm
16 different arrhythmia analyses
Non-Paced Patient Paced Patient
ASYSTOLE R on T ASYSTOLE
VFIB/VTAC PVC TACHY
COUPLET TACHY BRADY
VT>2 BRADY PNC
BIGEMINY MISSED BEATS
PNP
TRIGEMINY IRR
VENT VBRADY
