Edgetech 2050-DSS User Manual

2-10
2050-DSS Side Scan and Sub-Bottom System 0024048_REV_A
SPECIFICATION
VALUE
Construction
Steel Armored
Grip Type
PMI (wet end)
Cable Diameter
8.2mm (0.32 in)
Weight In Air
266 kg/km (179 lb/kft)
Weight in Seawater
222 kg/km (149 lb/kft)
Specific Gravity
6.2
Breaking Strength
42.7 kN (9,600 lbf)
Maximum Working Load
17.1 kN (3.844 ldf)
Minimum Bend Radius
18 cm (7.1 in.)
Voltage Rating
1200 VDC
DC Loop Resistance
33.5 Ω/km (10.2 Ω/kft)
Table 2-6: Armored Cable A320327 Specifications
